SpaGuts 25-150-0001 Universal Inline Bath Heater Kit, 1.5KW, 110V, 7x1.5 inches, with Built-in Pressure Switch

Description

SpaGuts 25-150-0001 Universal Inline Bath Heater Kit, 1.5KW, 110V, 7x1.5 inches, with Built-in Pressure Switch This is the 7.0 x 1.5 inch in-line style bathtub heater, designed to be installed on the PRESSURE SIDE of the bathtub pump. This bath heater is normally meant for use on 1.5 inch plumbing, but can also be used on 1.0 inch and 0.75 inch plumbing when using the fittings that are provided. Inside diameter is approximately 2.375 inch for the black heater split nuts. FEATURES: Stainless Steel 7.0 inch x 1.5 inch in-line heater 1.5kw 110V Incoloy heater element Built-in pressure switch to activate heating Automatic smart thermostat (104 degrees F limit) Reversible mounting Heater on light Hi-limit protection 1.5 inch, 1.0 inch and 3/4 inch pipe fittings included Pair of 1.5 inch Heater O-Ring Gaskets included 110V 60Hz 3ft NEMA cord Copper Bonding Wire included Installation and Operation Manual 2-year limited warranty UL Recognized for safety standards The Pressure Switch model bath heater is also a replacement option for the following model numbers: 10-305-1645, SG101-15UP, 20-15000-OB, 10-250-1645, PH101-15UP, 2-00-7512, 2-00-5007, 935212+21, 46-355-1048, CT100 (Pressure Switch Models Only), C3B83P1-D012JUZ, American Standard EZHEAT_100, 1000-030-364. This also fits on the following American Standard Whirlpool Bathtubs Model E, L, V and W: 2351, 2371, 2383, 2422, 2425, 2460, 2461, 2466, 2470, 2525, 2703, 2705, 2708, 2709, 2711, 2742, 2748, 2770, 2771, 2772, 2773, 2774, 2775, 2805, 2806, 2901, 2902, 2903, 2908, 293X, 294X, 2732, 7236, 7239, 7242, 357X, 6060, 6069. This bath heater is also a replacement option for the following brand bath heaters: American Standard, Safe-T-Heater, Hydro-Quip Compact Series Whirlpool Bath Heater, Jacuzzi RapidHeat, Pure Heat, Eljer 4941000-00, menards 6717550 NOTE: This bath heater is designed to maintain the current bath water temperature in the tub, and is not meant to heat water from cold to hot.
