Compact Generator Docking Station, 800 Amp, 120/208 Volts -3 Phase 3 Wire, NEMA 4/12 CAM Lock Input, Series 16 CAM connectors, Color Code BLK/RED/BLU/WHT/GRN, Portable Power Solution

Description

Introducing the Power Assemblies Generator Docking Station, a high-quality and cost-effective solution designed to facilitate quick connections for emergency power. With its NEMA 4/12 CAM lock quick connection system, this generator connection box integrates seamlessly with a transfer switch, providing an efficient way to ensure your backup power is ready when you need it most. Key Features: Versatile Size Options: Available in Mini, Compact, and Standard sizes, our docking station can handle power requirements from 400 Amps to 2000 Amps, making it ideal for a variety of applications in hospitals, data centers, emergency situations, and airports. Durable and Secure Construction: Crafted from 14 Ga. Carbon Steel, these lockable, watertight enclosures are built to withstand harsh conditions and are cULus Listed (UL1008) for safety and reliability. Efficient Connectivity: The Series 16 CAMs allow for quick and easy connections, ensuring that you can deploy emergency power swiftly and without hassle. Specifications: Available Sizes: Mini: 24”h x 20”w x 8”d Compact: 36”h x 30”w x 12”d Standard: 54”h x 35.7”w x 17.07”d Available Amps: 400A, 800A, 1200A, 1600A, 2000A Power Input: Series 16 CAMs Power Output: Silver-Plated Copper Bus Bar Mounting: Wall Mount Enclosure Finish: ANSI 61 Gray Enclosure Type: NEMA 4/12 Max Voltage: Up to 600 VAC (including 120/208V Y, 250V D, and 600V options) Phases/Wires Available: 3 Phases and 3 Wires or 3 Phases and 4 Wires Color Codes: Black (BLK), Red (RED), Blue (BLU), White (WHT), Green (GRN) Warranty: The Generator Docking Station comes with a one (1) year manufacturer’s warranty from the date of shipment, ensuring your peace of mind. PLEASE NOTE: The images shown are for illustration purposes only. Actual products may vary based on the specifications selected. Choose the Power Assemblies Generator Docking Station for a dependable and efficient solution to meet your emergency power needs, ensuring that you’re always prepared!

Photos

Product specs
